Question 1

What is true about Ethernet? (Choose Two.)

A.10BaseT half duplex
B.CSMA/CA Stops transmitting when congestion occurs
C.802.3 Protocol
D.CSMA/CD Stops transmitting when congestion occurs
E.802.2 Protocol

Question 2

Which set of commands is recommended to prevent the use of a hub in the access layer?

A.switch(config-if)#switchport mode trunk
switch(config-if)#switchport port-security mac-address 1
B.switch(config-if)#switchport mode access
switch(config-if)#switchport port-security maximum 1
C.switch(config-if)#switchport mode trunk
switch(config-if)#switchport port-security maximum 1
D.switch(config-if)#switchport mode access
switch(config-if)#switchport port-security mac-address 1

Question 3

Lab - VTP Configuration
A new switch is being added to the River Campus LAN. You will work to complete this process by first configuring the building_210 switch with an IP address and default gateway. For the switch host address, you should use the last available IP address on the management subnet. In addition, the switch needs to be configured to be in the same VTP domain as the building_100 switch and also needs to be configured as a VTP client. Assume that the IP configuration and VTP configuration on building_100 are complete and correct.
The configuration of the router is not accessible for this exercise. You must accomplish the following tasks:
Determine and configure the IP host address of the new switch.
Determine and configure the default gateway of the new switch.
Determine and configure the correct VTP domain name for the new switch.
Configure the new switch as a VTP client.

Correct Answer:

Here are the Steps for this Lab Solution:
The question states we can't access the router so we can only get required information from switch building_1. Click on the PC connected with switch building_1 (through a console line) to access switch building_1s CLI. On this switch use the show running-config command:
building_1#show running-config
Next use the show vtp status command to learn about the vtp domain on this switch building_1#show vtp status (Notice: the IP address, IP default-gateway and VTP domain name might be different!!!) You should write down these 3 parameters carefully.
Configuring the new switch
+ Determine and configure the IP host address of the new switch The question requires "for the switch host address, you should use the last available IP address on the management subnet".
The building_1 switch's IP address, which is 192.168.22.50 255.255.255.224, belongs to the management subnet.
Increment: 32 (because 224 = 1110 0000)
Network address: 192.168.22.32
Broadcast address: 192.168.22.63
->The last available IP address on the management subnet is 192.168.22.62 and it hasn't been used (notice that the IP address of Fa0/1 interface of the router is also the default gateway address 192.168.22.35).
Also notice that the management IP address of a switch should be configured in Vlan1 interface.
After it is configured, we can connect to it via telnet or SSH to manage it.
Switch2#configure terminal
Switch2(config)#interface Vlan1
Switch2(config-if)#ip address 192.168.22.62 255.255.255.224
Switch2(config-if)#no shutdown
+ Determine and configure the default gateway of the new switch The default gateway of this new switch is same as that of building_1 switch, which is 192.168.22.35 Switch2(config-if)#exit Switch2(config)#ip default-gateway 192.168.22.35
+ Determine and configure the correct VTP domain name for the new switch The VTP domain name shown on building_1 switch is Cisco so we have to use it in the new switch (notice: the VTP domain name will be different in the exam and it is case sensitive so be careful) Switch2(config)# vtp domain Cisco
+ Configure the new switch as a VTP client
Switch2(config)#vtp mode client
We should check the new configuration with the "show running-config" & "show vtp status"; also try pinging from the new switch to the the default gateway to make sure it works well.
Finally save the configuration
Switch2(config)#exit
Switch2#copy running-config startup-config

Question 4

Which three of these statements regarding 802.1Q trunking are correct? (Choose three.)

A.802.1Q trunks can use 10 Mb/s Ethernet interfaces.
B.802.1Q trunking ports can also be secure ports.
C.802.1Q trunks should have native VLANs that are the same at both ends.
D.802.1Q trunks require full-duplex, point-to-point connectivity.
E.802.1Q native VLAN frames are untagged by default.

Question 5

Which two steps must you perform on each device that is configured for IPv4 routing before you implement OSPFv3?(Choose two)

A.configure a router ID
B.configure a loopback interface
C.configure an autonomous system number
D.Enable IPv6 unicast routing
E.Enable IPv6 on an interface
