Question 106

Refer to the Exhibit.

After the switch configuration the ping test fails between PC A and PC B Based on the output for switch 1. which error must be corrected?

A.There is a native VLAN mismatch

B.Access mode is configured on the switch ports.

C.The PCs are m the incorrect VLAN

D.All VLANs are not enabled on the trunk

Question 107

In a CDP environment, what happens when the CDP interface on an adjacent device is configured without an IP address?

A.CDP becomes inoperable on that neighbor

B.CDP uses the IP address of another interface for that neighbor

C.CDP operates normally, but it cannot provide IP address information for that neighbor

D.CDP operates normally, but it cannot provide any information for that neighbor

Question 108

A port security violation has occurred on a switch port due to the maximum MAC address count being exceeded. Which command must be configured to increment the security-violation count and forward an SNMP trap?

A.switchport port-security vilation access

B.switchport port-security vilation protect

C.switchport port-security vilation restrict

D.switchport port-security vilation shutdown

Question 109

What are two requirements for an HSRP group? (Choose two.)

A.exactly one active router

B.one or more standby routers

C.one or more backup virtual routers

D.exactly one standby active router

E.exactly one backup virtual router

Question 110

Refer to the exhibit.

Router R1 Fa0/0 is unable ping router R3 Fa0/1.
Which action must be taken in router R1 to help resolve the configuration issue?

A.set the default network as 20.20.20.0/24

B.configure a static route with Fa0/1 as the egress interface to reach the 20.20.20.0/24 network

C.configure a static route with 10.10.10.2 as the next hop to reach the 20.20.20.0/24 network

D.set the default gateway as 20.20.20.2
