To ensure ProfiNET Layer 2 Class-of-Service markings from ProfiNET devices are trusted by the switch, which command must be entered on the interface attached to the device?

• A.switch(config-if)#profinet cos trust
• B.switch(config-if)#mls qos trust cos
• C.switch(config-if)#trust qos cos
• D.switch(config-if)#qos trust cos

Which statement is correct regarding Media Redundancy Protocol (MRP) in a ring of
ProfiNET devices?

• A.MRP is only supported on network switches
• B.MRP defines two device roles, Media Redundancy Master and Media Redundancy
  Client
• C.When a link fault is detected, MRP rings must converge in less than 100 milliseconds
• D.MRP can support rings of up to 250 devices

If the Link Fault alarm is connected to the minor relay and the FCS Bit Error Rate alarm is connected to the major relay, which commands will create an alarm profile called GigE with the alarms correctly mapped to the minor and major relays?

• A.Switch(config)#alarm profile GigE
  Switch(config-alarm-prof)#alarm 1 4
  Switch(config-alarm-prof)#relay major 4
  Switch(config-alarm-prof)#relay minor 1
• B.Switch(config)#alarm profile GigE
  Switch(config-alarm-prof)#alarm 1 3
  Switch(config-alarm-prof)#relay major 3
  Switch(config-alarm-prof)#relay minor 1
• C.Switch(config)#alarm profile GigE
  Switch(config-alarm-prof)#alarm 1 4
  Switch(config-alarm-prof)#relay major 1
  Switch(config-alarm-prof)#relay minor 4
• D.Switch(config)#alarm profile GigE
  Switch(config-alarm-prof)#alarm 1 3
  Switch(config-alarm-prof)#relay major 1
  Switch(config-alarm-prof)#relay minor 3

Refer to the exhibit.

L3SW1 has a spanning-tree priority of 8192 set on VLANs 1, 300, and 301, and these
VLANs are configured on and trunked between all switches. Executing the command show spanning-tree blockedports on L2SW5 results in:
L2SW5# show spanning-tree blockedports
Name Blocked Interfaces List
-------------------- ------------------------------------
VLAN0001 Gi1/1
VLAN0300 Gi1/1
VLAN0301 Gi1/1
An additional VLAN, VLAN302, is defined on all switches and trunked between them.
VLAN302 access ports are set up on each of the switches and PLC#1, I/O#1, and the
PanelView are attached. You expect the new VLAN to be listed as blocked on interface
GigabitEthernet1/1 of L2SW5 but it is not. The three new devices are able to communicate with each other.
After executing the same command on all switches you see this output on L2SW4:
L2SW4# show spanning-tree blockedports
Name Blocked Interfaces List
-------------------- ------------------------------------
VLAN0001 Gi1/2
VLAN0300 Gi1/2
VLAN0301 Gi1/2
Why is VLAN302 forwarding on L2SW5 interface GigabitEthernet 1/1 and L2SW4 interface
GigabitEthernet 1/1 and 1/2?

• A.L2SW4 is the spanning tree root for VLAN 302
• B.VLAN302 is not configured in the VLAN database on L2SW5
• C.The FO3 fiber-optic cable between L2SW4 and L2SW5 is damaged
• D.VLAN302 is not in the allowed list on the L2SW5 interface GigabitEthernet1/1 trunk

Your controller has a high performance EtherNet/IP interface with port speed of >30,000 packets per second and 80% spare capacity. A new PowerFlex 753 drive will be added to the system with an RPI of 2ms and has been connected to a switch; you have been asked to set up the switch port. You open the EDS file and see that the drive will support 16 CIP connections and has transmit and receive capacity of 1,000 control packets per second.
What do you set as the storm control pps threshold limit for the port?

• A.16
• B.1,000
• C.2,500
• D.25,000
