Online Access Free 300-070 Practice Test

If no SIP dial rules are configured on an IP phone, at which three points in the collection of digits does a Type A SIP phone send digits to the Cisco Unified Communications Manager? (Choose three.)

• A.when the interdigit timer expires
• B.when the user presses the Dial softkey
• C.as each digit is collected (it is sent for analysis)
• D.when the user presses the # key
• E.when the collected digits match a SIP dial rule

In the Cisco Unified Communications Manager Administration window, which MOH parameter can be selected for phones and gateways?

• A.hold stream source
• B.hold stream volume
• C.media loop timer
• D.media resource group list

Which configuration parameter may need to be adjusted when the Region setting is changed?

• A.Class of Control
• B.AAR Group
• C.Location
• D.Device Pool

By default, what value is voice traffic marked as on a Cisco Catalyst Switch?

• A.DSCP CAS6 value 21, Cos 3
• B.DSCP AF21 value 46, Cos 5
• C.DSCP EF value 46, Cos 7
• D.DSCP EF value 46, Cos 5

Refer to the exhibit. An engineer is working on a ticket that reports TEL1 cannot call TEL2.
These dial peers are configured to route the call between the endpoints.
dial-peer voice 2001voip
destination-pattern 2001
session protocol sipv2
session target ipv4:10.1.1.2
incoming called-number .
codec g722-64
video codec h264
dtmf-relay rtp-nte sip-notify sip-kpml
no vad
dial-peer voice 3001 voip
destination-pattern 3001
session protocol sipv2
session target ipv4:10.3.1.2
incoming called-number .
codec g722-64
video codec h264
dtmf-relay rtp-nte sip-notify sip-kpml
no vad
While troubleshooting, the engineer discovers that the Cisco Unified Border Element is giving the error "SIP/2.0 403 Forbidden".
Which two Cisco Unified Border Element configurations resolve this issue? (Choose two.)

• A.voice service voip
  mode border-element
  ip address trusted list
  ipv4 10.1.1.0 255.255.255.0
  ipv4 10.2.1.0 255.255.255.0
  allow-connections sip to sip
  sip
  bind control source-interface loopback0
  bind media source-interface loopback0
• B.voice service voip
  mode border-element
  ip address trusted list
  allow-connections sip to sip
  sip
  bind control source-interface loopback0
  bind media source-interface loopback0
• C.voice service voip
  mode border-element
  allow-connections sip to sip
  sip
  bind control source-interface loopback0
  bind media source-interface loopback0
• D.voice service voip
  no ip address trusted authenticate
  mode border-element
  allow-connections sip to sip
  sip
  bind control source-interface loopback0
  bind media source-interface loopback0
• E.voice service voip
  mode border-element
  ip address trusted list
  ipv4 10.1.1.0 255.255 255.0
  ipv4 10.3.1.0 255.255.255.0
  allow-connections sip to sip
  sip
  bind control source-interface loopback0
  bind media source-interface loopback0
