Online Access Free 300-080 Practice Test

Refer to the exhibit.

A CUCM user has been configured to use the Mobility feature and is expecting their home phone
408-555-6016 to ring simultaneously when their office phone is called. What configuration change needs to be made to allow this happen?

• A.Select the Enable Extend and Connect check box.
• B.Select the Line Association check box.
• C.Deselect the Enable Single Number Reach check box.
• D.Select the Enable Move to Mobile check box.

You have sites across a WAN and because of a recent change on the access control lists, your SIP phones are having registration issues.
Which cause is likely?

• A.TCP/UDP 6050 is blocked by the ACL.
• B.TCP/UDP 0506 is blocked by the ACL.
• C.TCP/UDP 5006 is blocked by the ACL.
• D.TCP/UDP 5060 is blocked by the ACL.

Refer to the exhibit.

A network administrator in Cisco recently configured ILS in the network. The administrator attempted a call to Joe's SIP URI ([email protected]), but the call failed. The administrator collected Cisco CallManager traces using Cisco Unified Communications Manager RTMT.
What should the administrator do to solve this issue?

• A.Check the "MTP Required" check box on the ILS trunk.
• B.Use the utils dbreplication reset all command to synchronize databases between ILS clusters.
• C.Joe's phone is currently using the SIP protocol. Change the protocol to SCCP.
• D.Create a route pattern for "americas" to route out the SIP trunk that is configured for the remote ILS cluster.

Refer to Exhibit:

What type of trace file is this considered to be?

• A.sdi
• B.calllogs
• C.dbnotify
• D.sdl
• E.dbl

Which call control model does MGCP use?

• A.Distributed
• B.Hybrid
• C.Ad hoc
• D.Centralized
