Online Access Free 300-410 Practice Test

Which two methods use IPsec to provide secure connectivity from the branch office to the
headquarters office? (Choose two.)

• A.SSL VPN
• B.PPPoE
• C.MPLS VPN
• D.DMVPN
• E.Virtual Tunnel Interface (VTI)

Refer to the exhibit. An engineer configured SNMP into Core_Sw1 to be able to upload
configurations. When the engineer tried to upload the configuration from the SNMP server, the
server failed to log in to the Core Sw1. Which configuration resolves the issue?

• A.snmp-server community Ciscowruser RW 20
• B.snmp-server group NETADMIN v3 priv read NETVIEW write NETADMIN access 10
• C.snmp-server community Cisc0Us3r RW 20
• D.snmp-server group NETVIEW v2c priv read NETVIEW access 11

Which of the following is true regarding IPsec Pre-fragmentation (Look-Ahead Fragmentation)?
(Choose two.)

• A.Operates in tunnel mode only
• B.Operates in transport mode only
• C.Does not support Path MTU Discovery
• D.Is used to help in the overall IPsec throughput since the end host is able to avoid packet
  reassembly after packet decryption.
• E.Is not dependent on the MTU of the physical interface used for IPsec.

Drag and Drop Question
Drag and drop the MPLS concepts from the left onto the descriptions on the right.

Correct Answer:

Explanation:
A label edge router (LER, also known as edge LSR) is a router that operates at the edge of an
MPLS network and acts as the entry and exit points for the network. LERspush an MPLS label
onto an incoming packet and pop it off an outgoing packet.
A forwarding equivalence class (FEC) is a term.

Which failure detection mechanism is used for BFD?

• A.routing protocol failure
• B.variable rate
• C.Layer 2 protocol failure
• D.consistent rate
