Question 6

How does an MPLS Layer 3 VPN function?

A.set of sites use multiprotocol BGP at the customer site for aggregation

B.multiple customer sites interconnect through service provider network to create secure tunnels between customer edge devices

C.set of sites interconnect privately over the Internet for security

D.multiple customer sites interconnect through a service provider network using customer edge to provider edge connectivity

Question 7

Exhibit:

Bangkok is using ECMP to reach to the 192.168.5.0/24 network. The administrator must configure Bangkok in such a way that Telnet traffic from 192.168.3.0/24 and192.168.4.0/24 networks uses the HongKong router as the preferred router. Which set of configurations accomplishes this task?

A.access-list 101 permit tcp 192.168.3.0 0.0.0.255 192.168.5.0 0.0.0.255 access-list 101 permit tcp 192.168.4.0 0.0.0.255 192.168.5.0 0.0.0.255
!
route-map PBR1 permit 10
match ip address 101
set ip next-hop 172.18.1.2
interface Ethernet0/3
ip policy route-map PBR1

B.access-list 101 permit tcp 192.168.3.0 0.0.0.255 192.168.5.0 0.0.0.255 eq 23 access-list 101 permit tcp 192.168.4.0 0.0.0.255 192.168.5.0 0.0.0.255 eq 23
!
route-map PBR1 permit 10
match ip address 101
set ip next-hop 172.18.1.2
interface Ethernet0/1
ip policy route-map PBR1

C.access-list 101 permit tcp 192.168.3.0 0.0.0.255 192.168.5.0 0.0.0.255 eq 23 access-list 101 permit tcp 192.168.4.0 0.0.0.255 192.168.5.0 0.0.0.255 eq 23
!
route-map PBR1 permit 10
match ip address 101
set ip next-hop 172.18.1.2
!
interface Ethernet0/3
ip policy route-map PBR1

D.access-list 101 permit tcp 192.168.3.0 0.0.0.255 192.168.5.0 0.0.0.255 access-list 101 permit tcp 192.168.4.0 0.0.0.255 192.168.5.0 0.0.0.255
!
route-map PBR1 permit 10
match ip address 101
set ip next-hop 172.18.1.2
!
interface Ethernet0/1
ip policy route-map PBR1

Question 8

Which 0S1 model is used to insert an MPLS label?

A.between Layer 1 and Layer 2

B.between Layer 5 and Layer 6

C.between Layer 2 and Layer 3

D.between Layer 3 and Layer 4

Question 9

Which statement about IPv6 RA Guard is true?

A.It does not offer protection in environments where IPv6 traffic is tunneled.

B.It cannot be configured on a switch port interface in the ingress direction.

C.Packets that are dropped by IPv6 RA Guard cannot be spanned.

D.It is not supported in hardware when TCAM is programmed.

Question 10

Which statement about route distinguishers in an MPLS network is true?

A.Route distinguishers define which prefixes are imported and exported on the edge router.

B.Route distinguishers are used for label bindings.

C.Route distinguishers make a unique VPNv4 address across the MPLS network.

D.Route distinguishers allow multiple instances of a routing table to coexist within the edge router.
