Free Access Cisco.300-620.v2022-08-20.q113 Practice Test (Page 7)

Question 26

How is an EPG extended outside of the ACI fabric?

A.Create an external bridged network that is assigned to a leaf port.

B.Create an external routed network that is assigned to an EPG.

C.Enable unicast routing within an EPG.

D.Statically assign a VLAN ID to a leaf port in an EPG.

Question 27

In the context of ACI Multi-Site, when is the information of an endpoint (MAC/IP) that belongs to site 1 advertised to site 2 using the EVPN control plane?

A.Endpoint information is exchanged across sites when the endpoints are discovered in both sites.

B.Endpoint information is not exchanged across sites unless a policy is configured to allow communication across sites.

C.Endpoint information is exchanged across sites as soon as the endpoint is discovered in one site.

D.Endpoint information is not exchanged across sites unless COOP protocol is used.

Question 28

Drag and drop the Cisco ACI filter entry options from the left onto the correct categories on the right indicating what are required or optional parameters.

Question 29

An engineer is implementing a Cisco ACI data center network that includes Cisco Nexus 2000 Series 10G fabric extenders. Which physical topology is supported?
A)
