Question 41

Refer to the exhibit. What must be configured in the service graph to redirect HTTP traffic between the EPG client and EPG server to go through the Cisco ASA firewall?

A.contract filter to allow ARP and HTTP

B.precise filter to allow only HTTP traffic

C.contract with no filter

D.permit-all contract filter

Question 42

Refer to the exhibit.

Two application profiles are configured in the same tenant and different VRFs. Which contract scope is configured to allow communication between the two application profiles?

A.VRF

B.application

C.global

D.tenant

Question 43

Refer to the exhibit.

Which two configuration steps are required in ISN for Cisco ACI Multi-Site setup? (Choose two.)

A.Configure BIDIR-PIM throughout the ISN

B.Enable IGMPv3 on ISN routers

C.Increase ISN MTU to support the maximum MTU that is sent by endpoints

D.Connect Spine2 to ISN routers.

E.Configure OSPF between spines and ISN routers

Question 44

Refer to the exhibit.

How are the STP BPDUs forwarded over Cisco ACI fabric?

A.STP BPDUs that are generated by Switch1 are received only by Switch3.

B.Cisco ACI acts as the STP root for all three external switches.

C.STP BPDUs that are generated by Switch2 are received by Switch1 and Switch3.

D.Cisco ACI fabric drops all STP BPDUs that are generated by the external switches.

Question 45

What is a design implication for Cisco ACI using an application-centric approach?

A.One EPG is mapped to multiple bridge domains

B.VLAN numbers are in the names of the bridge domain and EPG objects

C.Multiple VLANs and/or multiple EPGs are under one bridge domain

D.One VLAN equals one EPG equals one bridge domain
