With reference to the list trace station 1101 printout shown in the exhibit, what statement describes what happened during the time period of the trace?

• A.Station 1101 called station 1000, and the station answered, then station 1000 transferred to call to station 1001.
• B.Station 1101 called station 1000, unanswered; the call covered the station 1001.
• C.Station 1101 called station 1000, the unanswered call went to the voicemail, and finally station 1101 called 1001.
• D.Station 1101 called station, hung-up and finally called station 100.

You must add 500 new stations with a four digit length, starting with station 4500.
What information must you populate in the dial plan analysis form?

• A.Dialed String = 45; Total Length =4; Call type = sta
• B.Dialed String = 45; Total Length =4; Call type = ext
• C.Dialed String = 4; Total Length =4; Call type = sta
• D.Dialed String = 4; Total Length =4; Call type = ext

Through which Communication Manager interface do you add an H.248 gateway to CM?

• A.System Management Interface (SMI)
• B.System Access Terminal (SAT)
• C.System Platform Management Console
• D.Linux command line

AAR is used to route which type of traffic?

• A.Internal and External Networks
• B.Public Switched Telephone Network
• C.Internal/Private Network
• D.External/Public Network

You are a technician responsible for an Avaya Aura@ Communication Manager implementation. You need to connect your PC/laptop to the server for initial setup and administration, as well as, set up a PC/laptop for the customer for on-going administration.
From the following list, which method is best used for on-site access to Communication Manager?

• A.Through the service PC/laptop connected to the Secure Access Link (SAL) interface on the server using a crossover cable
• B.Through the service PC/laptop connected to the pre-configured CM IP address of 192.11.13.5
• C.Through the service PC/laptop connected to the services port on the server using a USB cable
• D.Through the service PC/laptop connected to the services port on the server using a crossover cable
