SIMULATION 7
Guidelines
This is a lab item in which tasks will be performed on virtual devices.
- Refer to the Tasks tab to view the tasks for this lab item.
- Refer to the Topology tab to access the device console(s) and perform the tasks.
- Console access is available for all required devices by clicking the device icon or using the tab(s) above the console window.
- All necessary preconfigurations have been applied.
- Do not change the enable password or hostname for any device.
- Save your configurations to NVRAM before moving to the next item.
- Click Next at the bottom of the screen to submit this lab and move to the next question.
- When Next is clicked, the lab closes and cannot be reopened.
Topology

Tasks
R1 and R2 currently have an eBGP connection. Configure and verify these tasks on R1 and R2:
1. Apply the preconfigured route map R1-TO-R2 and R1 to receive the R2 Loopback address on R1.
2. Apply the preconfigured route map R2-TO-R1 and R2 to receive the R1 Loopback address on R1.
3. R1 must advertise network 10.1.1.1/32 toward R2. Redistribution is not allowed.
4. R2 must advertise network 10.2.2.2/32 toward R1. Redistribution is not allowed.

Refer to the exhibit. During the last maintenance window, the network engineering team performed multiple software upgrades and enabled OSPFv3 for future use. However, when the network came up, the connection between HQ and the remote branch failed. A network engineer determined that routers R1 and R2 failed to establish an OSPFv2 adjacency. R1 was preconfigured with the point-to-point OSPF network type, and R2 as broadcast. The engineer confirmed that all connected interfaces are up, and the routers can reach one another via ICMP.
Which action must the engineer take to resolve the issue?

• A.Configure R1 and R2 with the same OSPFv3 router ID.
• B.Change the hello and dead intervals on the interfaces on R1 and R2 to the same values respectively.
• C.Set the R1 OSPFv2 process ID to match the R2 OSPFv2 process ID.
• D.Set the same network statement under the OSPFv2 configuration on R1 and R2.

A network engineer deployed Cisco MPLS TE tunnels on the service provider network to steer the traffic over those tunnels to optimize the bandwidth utilization.
Which two configurations can send the traffic to the Cisco MPLS TE tunnel interfaces? (Choose two.)

• A.enabling LFA calculation
• B.static route pointing down to the Cisco MPLS TE interface tunnel
• C.applying an explicit-path command under the Cisco MPLS TE interface tunnel
• D.applying the fast-reroute per-prefix command
• E.applying the autoroute announce command under the Cisco MPLS TE interface tunnel

Refer to the exhibit. In the service provider network, routers PE1, PE2, and PE4 have access to the internet and provide access to customer networks. Router PE3 is used for access to other customer systems. In accordance with a new SLA, an engineer is updating settings on this network so that router CE1 accesses the internet via PE1 instead of PE2. Which two tasks must the engineer perform to complete the process? (Choose two.)

• A.On PE2 and PE3, configure the internet VRF with import route target 101:101.
• B.On PE2, configure the CE1 VRF with import route target 101:101.
• C.On PE1, configure the internet VRF with import route target 102:102.
• D.On PE2, configure the internet VRF with import route target 102:102.
• E.On PE1 and PE4, configure the internet VRF with import route targets 102:102 and 104:104.

Refer to the exhibit. The customer that owns the CE-1, CE-2, and CE-3 routers purchased point- to-point E-Line services from the Carrier Ethernet provider. The service provider is delivering multiplexed UNI at the customer HQ location on PE-1 and untagged UNIs at the PE-2 and PE-3 locations. Additionally, the customer provided these VLAN to EVC mapping requirements:
- EVC 1 between CE-1 and CE-2 must be provisioned with C-VLAN 12 at the HQ location.
- EVC 2 between CE-1 and CE-3 must be provisioned with C-VLAN 13 at the HQ location.
Which configuration must the network engineer implement on the PE routers to provide end-to- end Carrier Ethernet service to the customer?

• A.
• B.
• C.
• D.
