Explanation Explanation To let FMC manages FTD, first we need to add manager from the FTD and assign a register key of your choice. The command configure manager add 1.1.1.2 the_registration_key_you_want, where 1.1.1.2 is the IP address of the FMC, you need to use the same registration key in FMC when adding this FTD as a managed device. Reference: https://cyruslab.net/2019/09/03/ciscocisco-firepower-lab-setup/ Explanation To let FMC manages FTD, first we need to add manager from the FTD and assign a register key of your choice. The command configure manager add 1.1.1.2 the_registration_key_you_want, where 1.1.1.2 is the IP address of the FMC, you need to use the same registration key in FMC when adding this FTD as a managed device.
Explanation Explanation To let FMC manages FTD, first we need to add manager from the FTD and assign a register key of your choice. The command configure manager add 1.1.1.2 the_registration_key_you_want, where 1.1.1.2 is the IP address of the FMC, you need to use the same registration key in FMC when adding this FTD as a managed device. Reference: https://cyruslab.net/2019/09/03/ciscocisco-firepower-lab-setup/

Reference:

As the new device does not have a supplicant, we cannot use 802.1X. MAC Authentication Bypass (MAB) is a fallback option for devices that don't support 802.1x. It is virtually always used in deployments in some way shape or form. MAB works by having the authenticator take the connecting device's MAC address and send it to the authentication server as its username and password. The authentication server will check its policies and send back an Access-Accept or Access-Reject just like it would with 802.1x. Cisco ISE Profiling Services provides dynamic detection and classification of endpoints connected to the network. Using MAC addresses as the unique identifier, ISE collects various attributes for each network endpoint to build an internal endpoint database. The classification process matches the collected attributes to prebuilt or user-defined conditions, which are then correlated to an extensive library of profiles. These profiles include a wide range of device types, including mobile clients (iPads, Android tablets, Chromebooks, and so on), desktop operating systems (for example, Windows, Mac OS X, Linux, and others), and numerous non-user systems such as printers, phones, cameras, and game consoles. Once classified, endpoints can be authorized to the network and granted access based on their profile. For example, endpoints that match the IP phone profile can be placed into a voice VLAN using MAC Authentication Bypass (MAB) as the authentication method. Another example is to provide differentiated network access to users based on the device used. For example, employees can get full access when accessing the network from their corporate workstation but be granted limited network access when accessing the network from their personal iPhone. Reference: https://community.cisco.com/t5/security-documents/ise-profiling-design-guide/ta-p/3739456 MAC Authentication Bypass (MAB) is a fallback option for devices that don't support 802.1x. It is virtually always used in deployments in some way shape or form. MAB works by having the authenticator take the connecting device's MAC address and send it to the authentication server as its username and password. The authentication server will check its policies and send back an Access-Accept or Access-Reject just like it would with 802.1x.
Cisco ISE Profiling Services provides dynamic detection and classification of endpoints connected to the network. Using MAC addresses as the unique identifier, ISE collects various attributes for each network endpoint to build an internal endpoint database. The classification process matches the collected attributes to prebuilt or user-defined conditions, which are then correlated to an extensive library of profiles. These profiles include a wide range of device types, including mobile clients (iPads, Android tablets, Chromebooks, and so on), desktop operating systems (for example, Windows, Mac OS X, Linux, and others), and numerous non-user systems such as printers, phones, cameras, and game consoles.
Once classified, endpoints can be authorized to the network and granted access based on their profile. For example, endpoints that match the IP phone profile can be placed into a voice VLAN using MAC Authentication Bypass (MAB) as the authentication method. Another example is to provide differentiated network access to users based on the device used. For example, employees can get full access when accessing the network from their corporate workstation but be granted limited network access when accessing the network from their personal iPhone.
As the new device does not have a supplicant, we cannot use 802.1X. MAC Authentication Bypass (MAB) is a fallback option for devices that don't support 802.1x. It is virtually always used in deployments in some way shape or form. MAB works by having the authenticator take the connecting device's MAC address and send it to the authentication server as its username and password. The authentication server will check its policies and send back an Access-Accept or Access-Reject just like it would with 802.1x. Cisco ISE Profiling Services provides dynamic detection and classification of endpoints connected to the network. Using MAC addresses as the unique identifier, ISE collects various attributes for each network endpoint to build an internal endpoint database. The classification process matches the collected attributes to prebuilt or user-defined conditions, which are then correlated to an extensive library of profiles. These profiles include a wide range of device types, including mobile clients (iPads, Android tablets, Chromebooks, and so on), desktop operating systems (for example, Windows, Mac OS X, Linux, and others), and numerous non-user systems such as printers, phones, cameras, and game consoles. Once classified, endpoints can be authorized to the network and granted access based on their profile. For example, endpoints that match the IP phone profile can be placed into a voice VLAN using MAC Authentication Bypass (MAB) as the authentication method. Another example is to provide differentiated network access to users based on the device used. For example, employees can get full access when accessing the network from their corporate workstation but be granted limited network access when accessing the network from their personal iPhone. Reference: https://community.cisco.com/t5/security-documents/ise-profiling-design-guide/ta-p/3739456

The FMC and managed devices communicate using a two-way, SSL-encrypted communication channel, which by default is on port 8305.
Cisco strongly recommends that you keep the default settings for the remote management port, but if the management port conflicts with other communications on your network, you can choose a different port. If you change the management port, you must change it for all devices in your deployment that need to communicate with each other.

Explanation The Firepower System uses network discovery and identity policies to collect host, application, and user data for traffic on your network. You can use certain types of discovery and identity data to build a comprehensive map of your network assets, perform forensic analysis, behavioral profiling, access control, and mitigate and respond to the vulnerabilities and exploits to which your organization is susceptible. The Cisco Advanced Malware Protection (AMP) solution enables you to detect and block malware, continuously analyze for malware, and get retrospective alerts. AMP for Networks delivers network-based advanced malware protection that goes beyond point-in-time detection to protect your organization across the entire attack continuum - before, during, and after an attack. Designed for Cisco Firepower network threat appliances, AMP for Networks detects, blocks, tracks, and contains malware threats across multiple threat vectors within a single system. It also provides the visibility and control necessary to protect your organization against highly sophisticated, targeted, zero-day, and persistent advanced malware threats.
