Online Access Free 3V0-643 Practice Test

You have been tasked with modifying an existing NSX API call to capture flow information for an organization. The existing API call is located on the ControlCenter desktop in a file name flowapi.txt.
The API call should be modified to collect Layer3 flow statistics between the dev-web-01a and the ControlCenter virtual machine.
Requirements:
vCenter: vcsa01a.corp.local
Credential: [email protected] / VMware1!
File location: flowapi.txt on the desktop of ControlCenter.
Modify and Save the existing API call to capture the requested information.
A REST Client has been added to Chrome and Firefox for this exercise.
Output the Response Body to a text file called apiresults.txt on the desktop of ControlCenter.
******************flowapi.txt***********************
https://<nsxmgr-ip>/api/2.1/app/flow/flowstats?contextId=datacenter-21&flowType=TCP_UDP&startTime
=0&endTime=
https://192.168.110.15/api/2.1/app/flow/flowstats?contextId=vm-26&flowType=Layer3&startTime=0&endT ime=1320917094000&
******************flowapi.txt***********************
HOL LAB for Practice:
See the explanation part for complete solution.

Correct Answer:

SOLUTION:
Access the MOB by entering the following URL
https://vcsa-01a.corp.local/mob
[email protected]
VMware1!




Note down the vm number of dev-web-01a (in exam its like vm-216)
Then update flowapi.txt as
******************flowapi.txt***********************
https://<nsxmgr-ip>/api/2.1/app/flow/flowstats?contextId=datacenter-21&flowType=TCP_UDP&startTime
=0&endTime=
https://192.168.110.15/api/2.1/app/flow/flowstats?contextId=vm-216&flowType=Layer3
&startTime=0&endTime=1320917094000&startIndex=0&pageSize=2
******************flowapi.txt***********************
Then go to RESTClient.
GET
https://192.168.110.15/api/2.1/app/flow/flowstats?contextId=vm-216&flowType=Layer3
&startTime=0&endTime=1320917094000&startIndex=0&pageSize=2
SEND
Copy the content of "Response Body"
Paste in notepad and Save As "apiresults.txt"on the desktop of ControlCenter.

Provide automatic IP assignment for the servers on the DEV-DB-Tier-01-NEW segment.
Requirements:
vCenter: vcsa-01a.corp.local
Credentials: [email protected] / VMware1!
Edge: Dev-Edge
Automatically allocate IP addreesses in the 172.16.30.100-149 range.
Lease time: 1 hour
Ensure hosts that receive an IP assignment will be able to reach the other Dev subnets.
The legacyhost-NEW with the MAC address 40:00:00:00:00:01 must always be assigned 172.16.30.99 Ensure other parameters match those of the dynamic allocation mechanism (Task1).
Enable logging with the highest level of detail for automatic IP allocations.
Ensure all requirements have been met.
NOTE:
Do not configure DHCP Relay agent on the Dev-DLR-NEW as this will be done by another administrator.
HOL LAB for Practice:
DHCP and other questions 7, 8, 9
See the explanation part for complete solution.

Correct Answer:

SOLUTION:


Add Pool as per given details:


Add Pool as per given details:

Create a security policy for specific web-based applications.
Requirements:
vCenter: vcsa-01a.corp.local
NSX Manager: 192.168.110.15
Credentials: [email protected] . VMware1!
New Security Policy Name: Web-Policy-NEW
New Web Security Group Name: Secure-Web-NEW
New NSX Tag: web-security-NEW
New App Security Group Names: Secure-App-NEW
Create a new security policy to deny HTTP/HTTPS from App server to the Web Server.
Create a new Security Group for the Web servers to meet the following requirements:
Existing and future virtual machines that have in their name dev-web should be added.
Any VM with a NSX tag of web-security-NEW should be added to this policy.
Ensure virtual machine dev-web-04a has been then tagged.
Create a new security group for the App server that has virtual machine dev-app-01a added.
HOL LAB for Practice:
See the explanation part for complete solution.

Correct Answer:

SOLUTION:
Requirements:







Create new Security Group = Secure-Web-NEW

In security tag put equal






Create new Security Policy as per given details:










Right Click -> Apply Policy ->
