Question 11

VPN-IPv4 addressing is made unique by defining an address structure consisting of:

A.A 64-bit Route Target followed by a 32-bit IPv4 address.

B.A 64-bit Route Distinguisher followed by a 32-bit IPv4 address.

C.A 32-bit Route Distinguisher followed by a 32-bit IPv4 address.

D.A 32-bit Route Target followed by a 32-bit IPv4 address.

Question 12

Which of the following commands may be used on an Alcatel-Lucent 7750 SR to display a network exported locally to BGP on the originating router? (Choose two)

A.Show router bgp neighbor <neighbor ip> advertised-routes

B.Show router bgp routes prefix <prefix>

C.Show router bgp routes

D.Show router bgp routes <prefix> hunt

E.Show router bgp routes <prefix> self-originated

Question 13

Click the exhibit.

The policy shown is configured on an Nokia 7750 SR to implement an extranet VPRN between the main sites of two separate VPRNs. Route target "target:65100:2" is used for Customer 1 routes, and route target "target:65100:3" is used for Extranet routes. How should this policy be applied?

A.The policy should be applied as an export policy on all the PEs connected to the sites of Customer 1.

B.The policy should be applied as an import policy on the PE connected to the main site of Customer 1.

C.The policy should be applied as an import policy on all the PEs connected to the sites of Customer 1.

D.The policy should be applied as an export policy on the PE connected to the main site of Customer 1.

Question 14

What is the minimum number of Route Distinguishers required to implement an overlapping VPRN involving 5 different customers?

A.1

B.3

C.5

D.7

E.10

Question 15

Click the exhibit.

A Carrier Supporting Carrier (CSC) VPRN is configured for a customer carrier who is a BGP/MPLS service provider. Which of the following describes the routes present in PE1's global routing table?

A.The system address of PE2 is present. The system addresses of CSC-PE1 and CSC-PE2 are not present.

B.The system addresses of PE2, CSC-PE1 and CSC-PE2 are all present.

C.The system address of CSC-CE1, the route 192.168.10.1, and the route 192.168.20.1 are all present.

D.The system address of PE2 and the route 192.168.20.1 are present.
