A BGP session is stuck in the "Connect" state. Which of the following is the most likely reason?

• A.The remote BGP peer is properly configured but the local router is not.
• B.The BGP protocol is administratively disabled on the remote BGP peer.
• C.The BGP protocol is administratively disabled on the local router.
• D.The local router is properly configured but the remote BGP peer is not.

Which of the following statements about BGP peering sessions is FALSE?

• A.BGP peers need IP reachability between them.
• B.eBGP peers have to be adjacent to each other.
• C.iBGP peers can be non-adjacent.
• D.BGP peers can be configured with different AS numbers.

Click the exhibit.

Routers RR1 and RR2 are route reflectors with the same Cluster-ID. How does router RA treat the updates for prefix 192.168.1.0/27 received from routers RR1 and RR2?

• A.Router RA prefers the update received from router RR1.
• B.Router RA flags both updates as invalid.
• C.Router RA accepts both updates and flags them as used.
• D.Router RA prefers the update received from router RR2.

An autonomous system has 7 routers configured with BGP. How many iBGP sessions are required for a fully meshed configuration?

• A.42
• B.7
• C.21
• D.13

Click the exhibit.

Router R1 is a route reflector with clients R2, R5 and R6. Prefixes advertised by router R5 have a local preference of 200. Router R3 advertises the prefix 192.168.1.0/27 to routers R5 and R6.
Assuming that none of the routers in AS 65540 is configured with "advertise-external", what is the expected output of "show router bgp routes" on router R5?

• A.Option A
• B.Option D
• C.Option B
• D.Option C
