To maximize your Key Vault through put rates, here are some recommended guidelines/best practices for maximizing your throughput:
Ensure you have throttling in place. Client must honor exponential back-off policies for 429's and ensure you are doing retries as per the guidance below.
Divide your Key Vault traffic amongst multiple vaults and different regions. Use a separate vault for each security/availability domain. If you have five apps, each in two regions, then we recommend 10 vaults each containing the secrets unique to app and region.
Reference:
https://docs.microsoft.com/en-us/azure/key-vault/general/overview-throttling

Explanation
The Network Watcher Network performance monitor is a cloud-based hybrid network monitoring solution that helps you monitor network performance between various points in your network infrastructure. It also helps you monitor network connectivity to service and application endpoints and monitor the performance of Azure ExpressRoute.
Note:
IP flow verify checks if a packet is allowed or denied to or from a virtual machine. The information consists of direction, protocol, local IP, remote IP, local port, and remote port. If the packet is denied by a security group, the name of the rule that denied the packet is returned. While any source or destination IP can be chosen, IP flow verify helps administrators quickly diagnose connectivity issues from or to the internet and from or to the on-premises environment.
IP flow verify looks at the rules for all Network Security Groups (NSGs) applied to the network interface, such as a subnet or virtual machine NIC. Traffic flow is then verified based on the configured settings to or from that network interface. IP flow verify is useful in confirming if a rule in a Network Security Group is blocking ingress or egress traffic to or from a virtual machine.
Reference:
https://docs.microsoft.com/en-us/azure/network-watcher/network-watcher-monitoring-overview
https://docs.microsoft.com/en-us/azure/network-watcher/network-watcher-ip-flow-verify-overview

References:
https://docs.microsoft.com/en-us/azure/active-directory/hybrid/how-to-connect-health-operations Overview Contoso,Ltd is a US-base finance service company that has a main office New York and an office in San Francisco.
Payment Processing Query System
Contoso hosts a business critical payment processing system in its New York data center. The system has three tiers a front-end web app a middle -tier API and a back end data store implemented as a Microsoft SQL Server 2014 database All servers run Windows Server 2012 R2.
The front -end and middle net components are hosted by using Microsoft Internet Inform-non Services (IK) The application rode is written in C# and middle- tier API uses the Entity framework to communicate the SQL Server database. Maintenance of the database e performed by using SQL Server Ago- The database is currently J IB and is not expected to grow beyond 3 TB.
The payment processing system has the following compliance related requirement
* Encrypt data in transit and at test. Only the front-end and middle-tier components must be able to access the encryption keys that protect the date store.
* Keep backups of the two separate physical locations that are at last 200 miles apart and can be restored for op to seven years.
* Support blocking inbound and outbound traffic based on the source IP address, the description IP address, and the port number
* Collect Windows security logs from all the middle-tier servers and retain the log for a period of seven years,
* Inspect inbound and outbound traffic from the from-end tier by using highly available network appliances.
* Only allow all access to all the tiers from the internal network of Contoso.
Tape backups ate configured by using an on-premises deployment or Microsoft System Center Data protection Manager (DPMX and then shaped ofsite for long term storage Historical Transaction Query System Contoso recently migrate a business-Critical workload to Azure. The workload contains a NET web server for querying the historical transaction data residing in azure Table Storage. The NET service is accessible from a client app that was developed in-house and on the client computer in the New Your office. The data in the storage is 50 GB and is not except to increase.
Information Security Requirement
The IT security team wants to ensure that identity management n performed by using Active Directory. Password hashes must be stored on premises only.
Access to all business-critical systems must rely on Active Directory credentials. Any suspicious authentication attempts must trigger multi-factor authentication prompt automatically Legitimate users must be able to authenticate successfully by using multi-factor authentication.
