The requirement states that load balancing decisions must be based on the number of active connections on each pool member. This directly maps to the Least Connections (member) load balancing method.
According to the BIG-IP Administration: Data Plane Configuration documentation:
* Least Connections (member) selects the pool member with the fewest active connections at the time of the request.
* This method dynamically adapts to real-time traffic patterns and ensures that more heavily loaded pool members receive fewer new connections.
* It is especially effective for web servers where connection duration may vary and equal distribution of active sessions is desired.
Why the other options are incorrect:
* B. Round RobinDistributes connections sequentially without considering current load or active connections.
* C. Ratio (member)Distributes traffic based on static ratios, not real-time connection counts.
* D. Ratio (node)Uses predefined ratios at the node level and does not account for active connection counts.
Correct Resolution:
Using Least Connections (member) ensures that new connections are directed to the pool member currently handling the fewest active connections, meeting the stated requirement.

This scenario requires unequal load distribution based on server capacity. The newer servers must receive more connections than the older ones, while still dynamically accounting for active connection counts.
According to BIG-IP Administration: Data Plane Configuration documentation:
Weighted Least Connections (member) combines:
Connection awareness (least connections)
Administrator-defined weights (ratios) to reflect server capacity
Pool members with higher weights receive proportionally more new connections than members with lower weights, even when using the same load balancing algorithm.
Why B is correct:
Allows assigning higher weights to newer servers and lower weights to older servers Ensures smarter traffic distribution based on both capacity and real-time load Why the other options are incorrect:
A . Global Availability
Used for disaster recovery and site failover, not intra-pool load distribution.
C . Round Robin
Distributes connections evenly without considering server capacity.
D . Least Connections (member)
Balances only by current connection count and does not account for differences in server performance or capacity.
Correct Resolution:
Use Weighted Least Connections (member) and assign higher weights to newer servers so they receive more traffic while protecting older servers from overload.

The configuration provided utilizes Priority Group Activation in conjunction with the min_active_members setting. Priority groups allow an administrator to define primary servers and "backup" servers within the same pool. The BIG-IP prioritizes traffic based on the assigned priority number, with the highest number receiving traffic first.
In this specific configuration, the priority 3 group is the primary group. Therefore, connections are first distributed to all pool members with priority 3 as long as they are available. The system will continue to use only the priority 3 group unless the number of available members in that group falls below the min_active_members value, which is set to 2.
If the priority 3 group has fewer than two active members, the BIG-IP "activates" the next available priority group (priority 2) and distributes traffic among the remaining members of priority 3 and all members of priority 2. This cascading logic continues down the list. Consequently, if both the priority 3 group and the priority 2 group have fewer than two members available, traffic is directed to the priority 1 group. This ensures that even in a multi-server failure scenario, the system has a last-resort group of servers to handle the traffic.
Option D is incorrect because if only one member of priority 3 goes down, there are still two members active (10.12.10.8 and 10.12.10.9). Since 2 is not less than the min_active_members threshold of 2, the priority 2 group will not yet be activated. Option B is incorrect because traffic flows from high priority to low priority, not the other way around.

To provide encrypted communication between users and a virtual server, the BIG-IP system acts as a transparent SSL/TLS proxy. The administrative configuration required for this is a Client SSL profile.
When multiple hostnames (FQDNs) are associated with a single IP address, the system must determine which SSL certificate to present to the client during the initial TLS handshake. This is achieved using an extension of the TLS protocol called Server Name Indication (SNI).
The configuration logic is as follows:
* Profile Type: The Client SSL profile is responsible for terminating the SSL connection from the client (the user) to the BIG-IP system.
* The Setting: Within the Client SSL profile (under the "Advanced" view), there is a field specifically called Server Name. By entering the specific hostname (e.g., www.example.com) in this field, the BIG- IP system can match the hostname requested by the client in the ClientHello message to the correct profile.
* Implementation: The administrator typically creates multiple Client SSL profiles-one for each hostname-and assigns them all to the same virtual server. One of these profiles must be designated as the Default SSL Profile for SNI to handle requests where the client does not provide a hostname or provides one that does not match any specific profile.
By using the Client SSL profile and the Server Name setting, the BIG-IP system ensures that each user receives the correct certificate for the specific site they are trying to reach, even though all sites share a single virtual server IP.

SSH is a Layer 4 TCP-based protocol that operates on TCP port 22 and does not use HTTP in any capacity. In the exhibit, the Virtual Server is configured with an HTTP Profile applied, which is inappropriate for SSH traffic and causes connection failures.
According to the BIG-IP Administration: Data Plane Configuration documentation:
An HTTP profile must only be applied to Virtual Servers handling HTTP or HTTPS traffic.
When an HTTP profile is attached, BIG-IP expects HTTP headers and attempts to parse application-layer data.
Non-HTTP protocols such as SSH, FTP (control), SMTP, and other raw TCP services will fail if an HTTP profile is enabled.
Why the other options are incorrect:
A . Set Protocol to UDP
SSH uses TCP, not UDP. Changing the protocol would break SSH entirely.
B . Set Source Address to 10.1.1.2
The source address setting controls client access restrictions and is unrelated to protocol parsing issues.
C . Set Destination Address/Mask to 0.0.0.0/0
The destination address is already valid for a specific SSH service and does not impact protocol handling.
Correct Resolution:
The BIG-IP Administrator should remove the HTTP Profile (set it to None) so the Virtual Server functions as a pure Layer 4 TCP service, allowing SSH connections to pass through successfully.
