An ArubaOS-CX is \ssmq DCBX on Interface 1/1/1. You enter this command:
show dcbx interface 1/1/1
Is this where you can see whether the connected converged network adapter (CNA) has accepted the application priorities advertised with DCBX?
Solution: in the Enhanced Transmission Selection (ETS) Local advertisement section

• A.Yes
• B.No

You enter this command on an ArubaOS-CX switch:
Switch# show erps status ring 1
Is this what the specified status means?
Solution: The status is Protection, which means that the ring is up and fully connected with the RPL port blocked.

• A.Yes
• B.No

The architect designs a spine and leaf network for a single data center that will use multiple leaf switches as Virtual Tunnel End Points (VTEP). The architect needs to select the type of Integrated Routing & Bridging (IRB) for the solution.
Is this statement about the IRB type true?
Solution: Asymmetric IRB routes packets in the ingress VTEP and then routes packets in the egress VTEP.

• A.Yes
• B.No

Is this how you should position switches in the ArubaOS-CX portfolio for data center networks?
Solution: Deploy Aruba 83xx switches as data center leaf switches.

• A.Yes
• B.No

Refer to the exhibit. Which shows the topology tot an Ethernet Ring Protection Switching (ERPS) solution.

Is this a valid design for the control and protected VLANs on the VSX fabric 1 switches?
Solution: Ring 1, Instance 1:
control VLAN: 51 protected VLANs: 51-100 Ring 1, Instance 2:
control VLAN: 51 protected VLANs: 101-150 Ring 2, Instance 1: control VLAN: 181 protected VLANs:
181-200 Ring 2, Instance 2: control VLAN: 181 protected VLANs: 201-220

• A.Yes
• B.No
