Explanation
BGP (Border Gateway Protocol) is a protocol designed to exchange routing and reachability information among autonomous systems (AS) on the internet1.
Option A is correct. When an EBGP router advertises routes to its neighbors, it appends its AS number to the AS_PATH attribute1. This is a key mechanism in BGP to prevent routing loops1.
Option C is correct. BGP has a built-in loop prevention mechanism whereby if a BGP router detects its own AS in the AS_PATH attribute, it will drop the prefix and will not continue to advertise it2. This helps to prevent routing loops2.
Option B is incorrect. EBGP routers do not accept routes that contain their own AS number in the AS_PATH2. Instead, they drop such routes as part of the loop prevention mechanism2.
Option D is incorrect. While it's true that EBGP routers append their AS number when advertising routes, they do not prepend their AS number1. The term "prepend" in BGP usually refers to a technique used to influence path selection by artificially lengthening the AS_PATH3.

Explanation
The management IP address of a device is the IP address that is used to access the device for configuration and monitoring purposes. It is usually assigned to a dedicatedmanagement interface that is separate from the data interfaces. The management interface can be accessed via SSH, Telnet, HTTP, or other protocols.
In the exhibit, the list of interfaces and their statuses shows that the management interface isme0. This interface has an admin status ofup, a protocol status ofinet, a local address of172.23.12.100/24, and a remote address ofunspecified. This means that the me0 interface is active, has an IPv4 address assigned, and is not connected to another device.
Therefore, the management IP address of the device shown in the exhibit is172.23.12.100.
References:
[Management Interfaces Overview] : [Displaying Interface Status Information]

Explanation
The Graceful Routing Engine Switchover (GRES) feature in Junos OS enables a router with redundant Routing Engines to continue forwarding packets, even if one Routing Engine fails1. GRES preserves interface and kernel information, ensuring that traffic is not interrupted1. However, GRES does not preserve the control plane1.
To preserve routing during a switchover, GRES must be combined with either Graceful Restart protocol extensions or Nonstop Active Routing (NSR)1. When GRES is combined with NSR, nearly 75 percent of line rate worth of traffic per Packet Forwarding Engine remains uninterrupted during GRES1. Any updates to the primary Routing Engine are replicated to the backup Routing Engine as soon as they occur1.
Therefore, when GRES is combined with NSR, routing is preserved and the new master RE does not restart rpd1.
