Online Access Free JN0-363 Practice Test

Exhibit

You confirm that the R2 and R3 routers are receiving a BGP route to the 203.0.113.0/24 network, but both routers display the route as hidden. Referring to the exhibit, which two actions solve this problem? (Choose two.)

• A.Apply the routing policy on R1 as an import policy to the IBGP group.
• B.Apply the routing policy on R1 as an export policy to the IBGP group.
• C.Configure a routing policy on R1 that sets the next hop for the 203.0.113.0/24 BGP route to the IP address that R1 uses for EBGP peering.
• D.Configure a routing policy on R1 that sets the next hop for the 203 0.113.0/24 BGP route to the IP address that R1 uses for IBGP peering.

Exhibit

You are advertising a summary route that represents your local network (172.20.0.0716) to both ISP A and ISPB. You want to influence all traffic sent to you from ISP C to go through R2.
How would you accomplish this task?

• A.On R1, prepend your AS number three times on the 172.20.0.0/16 route when advertising It to ISP 1.
• B.On R2. prepend your AS number three times on the 172.20.0.0/16 route when advertising it to ISP 2.
• C.On R1, change the local preference value to 250.
• D.On R2, change the local preference value to 50.

An OSPF router does not have a router ID configured.
In this scenario, which statement is correct about the router ID?

• A.The Junos OS will use the IP address assigned to the loopback interface for the router ID.
• B.The Junos OS will use the IP address assigned to the Interface with the highest priority.
• C.The Junos OS will use the IP address assigned to the interface with the lowest MAC address.
• D.A router ID will not be assigned until it is manually configured.

You have created a routing instance named vr3 that will provide access to Server 2 (10.0.0.2) (or the hosts on the 10.10.10.0/24 network. Which command would you use to test connectivity between vr3 and Server 2?

• A.user@vr3> ping 10.0.0.2 count 5
• B.user@vr3> ping 10.0.0.2 count 5 source 10.10.10.1
• C.user@router1> ping 10.0.0.2 routing-instance vr3 count 5
• D.user9router1> ping 10.0.0.2 count 5

Exhibit.

Referring to the exhibit, you have configured an aggregate route that represents the 172.21.0.0/24, 172.21.1.0/24, and 172.21.2.0/24 networks. However, when you view the routing table, your new route hidden.
Which action would you perform to determine the problem?

• A.Verify that you have active contributing routes on the device.
• B.Verify that you have set the preference to a lower default value.
• C.Verify that you have defined a metric value for the aggregate route.
• D.Verify that you have configured a policy on the device to accept aggregate routes.
