Online Access Free JN0-662 Practice Test

You are configuring a BGP-signaled Layer 2 VPN service.
Which two statements are true in this scenario? (Choose two.)

• A.RSVP-signaled LSPs are required.
• B.RSVP-signaled or LDP-signaled LSPs may be used.
• C.The family 12vpn auto-discovery-only parameter is required for BGP sessions.
• D.The family 12vpn signaling parameter is required for BGP sessions.

Click the exhibit button.

What would be the expected outcome from the configuration shown in the exhibit?

• A.The VPLS instance would cycle through all physical interfaces configured on the router to find one to use.
• B.The VPLS instance would cycle through all virtual tunnel interfaces on the router to find one to use.
• C.The VPLS instance would use a control-word instead of a tunnel-services interface, or no-tunnel-services parameter.
• D.The VPLS instance would default to using no-tunnel-services because a tunnel-services interface was not specified.

You are currently running BGP-based VPLS and Layer 3 VPNs. You are asked to consolidate the services and deploy EVPN to replace the VPLS and Layer 3 VPN deployments.
Which two EVPN route types will achieve this goal? (Choose two.)

• A.Type 4
• B.Type 2
• C.Type 5
• D.Type 7

How is a BGP Layer 2 VPN prefix formed by a PE?

• A.by combining the route distinguisher and vrf-target, in that order
• B.by combining the vrf-target and route distinguisher, in that order
• C.by combining the route distinguisher, site identifier, and remote site identifier, in that order
• D.by combining the route distinguisher, remote site identifier, and site identifier, in that order

Click the Exhibit button.

Referring to the exhibit, RR1-RR4 are route reflectors.
Which three routers would RR1 need to peer with if the no-client-reflect parameter has been configured? (Choose three.)

• A.R5
• B.R6
• C.R1
• D.RR4
• E.R2
