Online Access Free JN0-682 Practice Test

You are implementing an EVPN overlay in your IP fabric data center. The IP fabric was stable before configuring the overlay group and EVPN-related settings. After committing the configuration shown in the exhibit on your spine device, you are no longer exchanging any routes in your underlay fabric.

In this scenario, what will solve this problem?

• A.You must remove the multipath parameter from the overlay group.
• B.You must move the EVPN NLRI family declaration to be applied under the overlay BGP group.
• C.You must remove the export policy applied to your fabric group.
• D.You must change the overlay group to establish an EBGP peering instead of IBGP.

Referring to the VTEP output shown in the exhibit, which two statements are true? (Choose two.)

• A.The MAC address 52:54:00 2c 4b:a2 belongs to a local host.
• B.The MAC address 52:54:00 2c 4b:a2 belongs to a remote host.
• C.The. MAC address 52:54:00 5e 88 6a belongs to a remote host.
• D.The MAC address 52:54;00 5e 88 6a belongs to a local host.

Which event triggers the generation of a EVPN type-4 route?

• A.When a new VNI is configured.
• B.When unknown unicast traffic is received on an interface.
• C.When a new ESI is configured.
• D.When known unicast traffic is received on an interface.

You are deploying a VXLAN using signaling overlay network in your new data center. You are able to establish your MP BGP peering session and see your EVPN routes, but traffic will not traverse the VXLAN using signaling overlay network.
What is a solution to this problem?

• A.Increase the physical MTU on all ports on all devices participating in VXLAN using EVPN signaling.
• B.Enable the mtu-discovery feature on the MP peering sessions between VXLAN ANs EVPN signaling peers.
• C.Increase the protocol MTU on all devices participating in VXLAN using EVPN signaling
• D.Increase the MTU on the logical VTEP source interface of all devices participating in VXLAN using EVPN signaling.

You are an architect for an enterprise organization that currently operates three data centers with plans to expand to five data centers in the next year. You already notice large amounts of BUM flooding and must control this issue before implementing the next two data centers.
Which feature would address this issue?

• A.mesh groups
• B.VXLAN BUM traffic filter
• C.type-5 routes
• D.type-6 routes
