Question 61
How many arrows can go out of an input parameter node?
Question 62
In the exhibit, which relationship may have extension points attached to it? Exhibit: 100-b-73.jpg
Question 63
Which icons are a standard representation for an actor? (Choose three)
Question 64
What ordering statement is correct about event occurrences of the interaction Q2 in the exhibit?
Denote sending of p as !p and receiving p as ?p.
Denote sending of p as !p and receiving p as ?p.
Question 65
How many diamond shapes can appear in a well-defined activity diagram?
