Free Access Avaya.72200X.v2022-05-02.q76 Practice Test (Page 8)

Question 31

Refer to the Exhibits.

The SIP call flow made from an Avaya Communicator Remote Worker is on the left,and the call flow made from a 96X1 telephone Remote Worker is on the right.
When comparing the two call flows, which statement is true?

A.The Communicator does not register to Avaya Aura Session Manager.

B.Avaya Aura Communication Manager does full call model processing for the SIP-to-SIP call flow and does half-call model processing for the SIP-to-Communicator call flow.

C.The Communicator registers to Avaya Session Border Controller for Enterprise (SBCE).

D.There is no difference between the two.

Question 32

When viewing the Avaya Aura System Manager (SMGR) alarms, which alarm information is particularly useful for finding more information in the available documentation?

A.M/E Ref Number/SysOID

B.NotificationOID

C.Event ID

D.Status

E.Source IP address

Question 33

When an Avaya SIP Telephone (AST) makes a call to another AST on the same Avaya Aura Communication Manager (CM), when is a SIP trunk used?

A.up to the point wherecalls are shuffled to establish a direct media path

B.just during call establishment and clear down only

C.for the entire duration of the call

D.only when the media path is established

Question 34

Which three statements about media-processing resources (DSPs)are true? (Choose three.)

A.Two-party calls originated by SIP stations or trunks, and terminated by H.323 trunks, media gateways, or other vendors' H.323 stations, will typically shuffle if CM is configured to do so.

B.Two-party calls originated by H.323 stations, trunks, or media gateways, and terminated by SIP stations or trunks, cannot shuffle.

C.SIP-SIP two-party calls will always use SIP Direct Media if Communication Manager (CM) is configured to do so.

D.H.323-H.323 two-party calls will always shuffle to establish a direct media path if CM is configured to do so.

E.If a direct media path cannot be established between two IP endpoints the call will fail from release
7.0.

Question 35

When a 96xx telephone with SIP firmware boots up, it goes through a number of steps. These steps include:
1. Phone Registration
2. Download PPM.
3. Obtain IP Address and http/https server address from DHCP Server.
4. Check if firmware upgrade is required and download 46xxsettings.txt file.
5. Send Subscribe (avaya-cm-feature-status) to Avaya Aura Communication Manager (CM) via Avaya Aura Session Manager (SM).
What is the correct sequence of these steps?

A.3, 4, 2, 1, 5

B.4, 3, 1, 2, 5

C.3, 4, 1, 5, 2

D.3, 5, 1, 2, 4
