Explanation:
Yes, Yes, No

See the Explanation below for step by step instructions
Explanation:
Here are the steps and explanations for creating a policy that can be linked to the planned application gateway and block connections from IP addresses in the 131.107.150.0/24 range:
To create a policy, you need to go to the Azure portal and select Create a resource. Search for WAF, select Web Application Firewall, then select Create1.
On the Create a WAF policy page, Basics tab, enter or select the following information and accept the defaults for the remaining settings:
Policy for: Regional WAF (Application Gateway)
Subscription: Select your subscription name
Resource group: Select your resource group
Policy name: Type a unique name for your WAF policy
On the Custom rules tab, select Add a rule to create a custom rule that blocks connections from IP addresses in the 131.107.150.0/24 range2. Enter or select the following information for the custom rule:
Rule name: Type a unique name for your custom rule
Priority: Type a number that indicates the order of evaluation for this rule Rule type: Select Match rule Match variable: Select RemoteAddr Operator: Select IPMatch Match values: Type 131.107.150.0/24 Action: Select Block On the Review + create tab, review your settings and select Create to create your WAF policy1.
To link your policy to the planned application gateway, you need to go to the Application Gateway service in the Azure portal and select your application gateway3.
On the Web application firewall tab, select your WAF policy from the drop-down list and select Save

See the Explanation below for step by step instructions.
* To deploy a firewall to subnetl-2, you need to create a network virtual appliance (NVA) in the same virtual network as subnetl-2. An NVA is a virtual machine that performs network functions, such as firewall, routing, or load balancing1.
* To create an NVA, you need to create a virtual machine in the Azure portal and select an image that has the firewall software installed. You can choose from the Azure Marketplace or upload your own image2.
* To assign the IP address of 10.1.2.4 to the NVA, you need to create a static private IP address for the network interface of the virtual machine. You can do this in the IP configurations settings of the network interface3.
* To ensure that traffic from subnetl-1 to the IP address range of 192.168.10.0/24 is routed through the NVA, you need to create a user-defined route (UDR) table and associate it with subnetl-1. A UDR table allows you to override the default routing behavior of Azure and specify custom routes for your subnets4.
* To create a UDR table, you need to go to the Route tables service in the Azure portal and select + Create. You can give a name and a resource group for the route table5.
* To create a custom route, you need to select Routes in the route table and select + Add. You can enter
* the following information for the route5:
* Destination: 192.168.10.0/24
* Next hop type: Virtual appliance
* Next hop address: 10.1.2.4
* To associate the route table with subnetl-1, you need to select Subnets in the route table and select + Associate. You can select the virtual network and subnet that you want to associate with the route table5.
