Question 86

In the topology shown in the figure, the following configurations are performed on RTA, RTB, RTC and RTD respectively:
RTA-LoopBack0] ip address 1.1.1.1 255.255.255.255
RTA]ospf 1
RTA-ospf-1]area 1
RTA-ospf-1-area-0.0.0.1]network 10.0.0.0 0.0.0.255
RTA-ospf-1]import-route direct
RTB-LoopBack0] ip address 2.2.2.2 255.255.255.255
RTB]ospf 1
RTB-ospf-1]area 1
rtb-ospf-1-area-0.0.0.1]network 10.0.0.0 0.0.0.255
RTB-ospf-1-area-0.0.0.1]area 0
rtb-ospf-1-area-0.0.0.0]network 2.2.2.2 0.0.0.0
RTB-ospf-1-area-0.0.0.0]network 20.0.0.0 0.0.0.255
RTC-LoopBack0] ip address 3.3.3.3 255.255.255.255
rtc]ospf 1
RTC-ospf-1]area 0
RTC-ospf-1-area-0.0.0.0]network 20.0.0.0 0.0.0.255
rtc-ospf-1-area-0.0.0.0]area 2
RTC-ospf-1-area-0.0.0.2]nssa no-import-route no-summarRTC-ospf-1-area-0.0.0.2]network 30.0.0.0
0.0.0.255
RTC-ospf-1]import-route direct
RTD-LoopBack0] ip address 4.4.4.4 255.255.255.255
RTD]ospf 1
RTD-ospf-1]area 2
RTD-ospf-1-area-0.0.0.2]network 30.0.0.0 0.0.0.255
RTD-ospf-1-area-0.0.0.2]network 4.4.4.4 0.0.0.0
rtd-ospf-1-area-0.0.0.2]nssa
then _______ may not be injected in zone 2
  • Question 87

    Which of the following statements about PBR is correct is _________
  • Question 88

    The following functions of the convergence layer are ______. (Choose one or more)
  • Question 89

    The following functions that belong to the access layer are ________. (select one or more)
  • Question 90

    In the IS-IS network as shown in the figure, when the routing is stable, the link between RTB and RTD is increased from the address network segment 192.168.224.0/24, then IS-IS topology ______, IP routing information ______ .
