Question 221

RTA and RTB run OSPF routing protocol, and both belong to the backbone area.
Which of the following methods can be used to advertise the RTA direct route 192.168.1.0/24 to the OSPF routing domain?
  • Question 222

    In the topology shown in the figure, the following configurations are performed on RTA, RTB, and RTC:
    RTA]ospf 1
    RTA-ospf-1]area 1
    RTA-ospf-1-area-0.0.0.1]network 10.0.0.0 0.0.0.255
    RTB]ospf 1
    RTB-ospf-1]area 1
    RTB-ospf-1-area-0.0.0.1]network 10.0.0.0 0.0.0.255
    RTB-ospf-1-area-0.0.0.1]area 0
    RTB-ospf-1-area-0.0.0.0]network 20.0.0.0 0.0.0.255
    RTC]ospf 1
    RTC-ospf-1]area 0
    RTC-ospf-1-area-0.0.0.0]network 20.0.0.0 0.0.0.255
    RTC-ospf-1-area-0.0.0.0]area 2
    RTC-ospf-1-area-0.0.0.2]stub
    RTC-ospf-1-area-0.0.0.2]network 30.0.0.0 0.0.0.255
    How to configure if RTD can learn route 10.0.0.0/24?
  • Question 223

    As shown in the figure, RTA is the border router of OSPF routing domain and BGP routing domain. If a BGP route with a MED value of 200 is imported into OSPF on RTA, the COST value of the route learned by RTB is ______ by default.
  • Question 224

    In the topology shown in the figure, the following configurations are performed on RTA and RTB respectively:
    RTA]ospf 1
    RTA-ospf-1]area 1
    RTA-ospf-1-area-0.0.0.1]network 10.0.0.0 0.0.0.255
    RTB]ospf 1
    RTB-ospf-1]area 1
    rtb-ospf-1-area-0.0.0.1]network 10.0.0.0 0.0.0.255
    RTB-ospf-1-area-0.0.0.1]area 0
    RTB-ospf-1-area-0.0.0.0]network 20.0.0.0 0.0.0.255
    If area 2 needs to be configured as a TotalStub area, how should it be configured on RTC and RTD?
  • Question 225

    Regarding the default metric values ​​for route import by different routing protocols, which of the following descriptions is __________
