When a user accesses the virtual gateway, the user can access the SSL VPN only after the user terminal passes the host check policy.
Correct Answer: A
Comprehensive and Detailed Explanation: * Host check policyis a security mechanism inSSL VPNto verifyterminal security compliancebefore granting access. * It checks for: * Antivirus software * Operating system patches * Running processes * Security settings * If the terminal fails the host check, access is denied. * Why is this statement true? * A successful host check is required before an SSL VPN session is allowed. HCIP-Security References: * Huawei HCIP-Security Guide # SSL VPN Host Check Policy
Question 7
In the figure, if 802.1X authentication is used for wired users on the network, the network admission device and terminals must be connected through a Layer 2 network. Options:
Correct Answer: A
Understanding 802.1X Authentication in Wired Networks: * 802.1X is a port-based network access control (PNAC) protocolthat requires aLayer 2 connection between thesupplicant (PC), the authenticator (switch), and the authentication server (e.g., RADIUS server). * In wired networks,802.1X authentication occurs at the Ethernet switch (Layer 2 device), which enforces authenticationbefore allowing network access. Why Must the Network Be Layer 2? * 802.1X authentication operates at Layer 2 (Data Link Layer) before any IP-based communication (Layer 3) occurs. * If the authentication device and user terminal were on different Layer 3 networks, the authentication packets (EAPOL - Extensible Authentication Protocol Over LAN)would not be forwarded. * In the figure, the authentication control point is at theaggregation switch, which means thePC and switch must be in the same Layer 2 domain. Components of 802.1X Authentication in the Figure: * Supplicant (PC)# The device requesting network access. * Authenticator (Aggregation Switch)# The switch controlling access to the network based on authentication results. * Authentication Server (iMaster NCE-Campus & AD Server)# Verifies user credentials and grants or denies access. * Layer 2 Connectivity Requirement# ThePC must be in the same Layer 2 networkas the Authenticatorto communicate via EAPOL. Why "TRUE" is the Correct answer: * 802.1X authentication is performed before IP addresses are assigned, meaning it can only operate in a Layer 2 network. * EAPOL (Extensible Authentication Protocol Over LAN) messages are not routableand must stay within a single Layer 2 broadcast domain. * In enterprise networks,VLAN-based 802.1X authentication is often used, where authenticated users are assigned to a specific VLAN. HCIP-Security References: * Huawei HCIP-Security Guide# 802.1X Authentication in Enterprise Networks * Huawei iMaster NCE-Campus Documentation# Authentication Control and NAC Deployment * IEEE 802.1X Standard Documentation# Layer 2 Network Authentication
Question 8
IPsec VPN does not support encapsulation of non-IP unicast packets.
Correct Answer: A
Comprehensive and Detailed Explanation: * IPsec VPN only supports IP unicast traffic. * Non-IP unicast packets (such as multicast and broadcast) are not natively supported. * To transmit multicast traffic over IPsec, GRE over IPsec is required. * Why is this statement true? * Standard IPsec VPN does not support non-IP unicast packets. HCIP-Security References: * Huawei HCIP-Security Guide # IPsec VPN Limitations
Question 9
Before configuring DDoS attack defense, you must configure different thresholds for defense against different types of attacks. Each threshold can be considered an upper limit for normal network traffic. When the rate of traffic exceeds the pre-configured threshold, the firewall considers it to be attack traffic and takes a corresponding action to defend against it.
Correct Answer: A
Comprehensive and Detailed Explanation: * DDoS defense mechanisms rely on threshold settingsto distinguish between normal and attack traffic. * Thresholds define: * Maximumallowedtraffic volume. * When exceeded, firewallstrigger mitigation actions(blocking, rate-limiting, etc.). * Why is this statement true? * Threshold-based detection is a fundamental part of DDoS mitigation. HCIP-Security References: * Huawei HCIP-Security Guide # DDoS Attack Prevention Thresholds
Question 10
In a Huawei network security environment, which of the following is a key advantage of using HWTACACS over RADIUS for device management authentication? Options:
Correct Answer: B
Understanding the Differences Between HWTACACS and RADIUS: * HWTACACS(Huawei Terminal Access Controller Access-Control System) is aHuawei-enhanced version of TACACS+used forAAA (Authentication, Authorization, and Accounting). * RADIUS (Remote Authentication Dial-In User Service)is also an AAA protocol but is mainly designed fornetwork access authentication, such asVPNs and wireless authentication. Why is Option B Correct? * HWTACACS supports per-command authorization, meaning administrators canassign different command privileges to different users. * For example, ajunior network engineer may be allowed to view configurations but not modify them , while asenior engineer has full access. * RADIUS does not support granular command authorization, as it primarily controlsnetwork access rather than device management.
