Question 151

Case Study: 6 - TerramEarth
Company Overview
TerramEarth manufactures heavy equipment for the mining and agricultural industries. About
80% of their business is from mining and 20% from agriculture. They currently have over 500 dealers and service centers in 100 countries. Their mission is to build products that make their customers more productive.
Solution Concept
There are 20 million TerramEarth vehicles in operation that collect 120 fields of data per second.
Data is stored locally on the vehicle and can be accessed for analysis when a vehicle is serviced.
The data is downloaded via a maintenance port. This same port can be used to adjust operational parameters, allowing the vehicles to be upgraded in the field with new computing modules.
Approximately 200,000 vehicles are connected to a cellular network, allowing TerramEarth to collect data directly. At a rate of 120 fields of data per second with 22 hours of operation per day, TerramEarth collects a total of about 9 TB/day from these connected vehicles.
Existing Technical Environment
TerramEarth's existing architecture is composed of Linux and Windows-based systems that reside in a single U.S. west coast based data center. These systems gzip CSV files from the field and upload via FTP, and place the data in their data warehouse. Because this process takes time, aggregated reports are based on data that is 3 weeks old.
With this data, TerramEarth has been able to preemptively stock replacement parts and reduce unplanned downtime of their vehicles by 60%. However, because the data is stale, some customers are without their vehicles for up to 4 weeks while they wait for replacement parts.
Business Requirements
Decrease unplanned vehicle downtime to less than 1 week.
* Support the dealer network with more data on how their customers use their equipment to better
* position new products and services
Have the ability to partner with different companies - especially with seed and fertilizer suppliers
* in the fast-growing agricultural business - to create compelling joint offerings for their customers.
Technical Requirements
Expand beyond a single datacenter to decrease latency to the American Midwest and east
* coast.
Create a backup strategy.
* Increase security of data transfer from equipment to the datacenter.
* Improve data in the data warehouse.
* Use customer and equipment data to anticipate customer needs.
* Application 1: Data ingest
A custom Python application reads uploaded datafiles from a single server, writes to the data warehouse.
Compute:
Windows Server 2008 R2
* - 16 CPUs
- 128 GB of RAM
- 10 TB local HDD storage
Application 2: Reporting
An off the shelf application that business analysts use to run a daily report to see what equipment needs repair. Only 2 analysts of a team of 10 (5 west coast, 5 east coast) can connect to the reporting application at a time.
Compute:
Off the shelf application. License tied to number of physical CPUs
* - Windows Server 2008 R2
- 16 CPUs
- 32 GB of RAM
- 500 GB HDD
Data warehouse:
A single PostgreSQL server
* - RedHat Linux
- 64 CPUs
- 128 GB of RAM
- 4x 6TB HDD in RAID 0
Executive Statement
Our competitive advantage has always been in the manufacturing process, with our ability to build better vehicles for lower cost than our competitors. However, new products with different approaches are constantly being developed, and I'm concerned that we lack the skills to undergo the next wave of transformations in our industry. My goals are to build our skills while addressing immediate market needs through incremental innovations.
For this question, refer to the TerramEarth case study. You need to implement a reliable, scalable GCP solution for the data warehouse for your company, TerramEarth. Considering the TerramEarth business and technical requirements, what should you do?
  • Question 152

    Your company has decided to build a backup replica of their on-premises user authentication PostgreSQL database on Google Cloud Platform. The database is 4 TB, and large updates are frequent. Replication requires private address space communication. Which networking approach should you use?
  • Question 153

    For this question, refer to the Mountkirk Games case study.
    Mountkirk Games wants to set up a continuous delivery pipeline. Their architecture includes many small services that they want to be able to update and roll back quickly. Mountkirk Games has the following requirements:
    * Services are deployed redundantly across multiple regions in the US and Europe.
    * Only frontend services are exposed on the public internet.
    * They can provide a single frontend IP for their fleet of services.
    * Deployment artifacts are immutable.
    Which set of products should they use?
  • Question 154

    As part of their new application experience, Dress4Wm allows customers to upload images of themselves.
    The customer has exclusive control over who may view these images.
    Customers should be able to upload images with minimal latency and also be shown their images quickly on the main application page when they log in.
    Which configuration should Dress4Win use?
  • Question 155

    Your company has a Google Workspace account and Google Cloud Organization Some developers in the company have created Google Cloud projects outside of the Google Cloud Organization You want to create an Organization structure that allows developers to create projects, but prevents them from modifying production projects You want to manage policies for all projects centrally and be able to set more restrictive policies for production projects You want to minimize disruption to users and developers when business needs change in the future You want to follow Google-recommended practices How should you design the Organization structure?
