Explanation:
The correct order of the rule processing steps of the Distributed Firewall is as follows:
- Packet arrives at vfilter connection table. If matching entry in the table, process the packet.
- If connection table has no match, compare the packet to the rule table.
- If the packet matches source, destination, service, profile and applied to fields, apply the action defined.
- If the rule table action is allow, create an entry in the connection table and forward the packet.
- If the rule table action is reject or deny, take that action.
This order is based on the description of how the Distributed Firewall works in the web search results. The first step is to check if there is an existing connection entry for the packet in the vfilter connection table, which is a cache of flow entries for rules with an allow action. If there is a match, the packet is processed according to the connection entry. If there is no match, the packet is compared to the rule table, which contains all the security policy rules. The rules are evaluated from top to bottom until a match is found. The match criteria include source, destination, service, profile and applied to fields. The action defined by the matching rule is applied to the packet. The action can be allow, reject or deny. If the action is allow, a new connection entry is created for the packet and the packet is forwarded to its destination. If the action is reject or deny, the packet is dropped and an ICMP message or a TCP reset message is sent back to the source.

NSX Intelligence provides a visual overview of network connections within the NSX domain, allowing administrators to see the traffic flows between different VMs and networks. It offers detailed visibility into network traffic patterns, application dependencies, and security posture, making it a valuable tool for monitoring and troubleshooting within NSX environments.

To enable stateful active-active SNAT on a Tier-0 or Tier-1 gateway, you must configure an Interface Group for the NSX Edge uplinks. An Interface Group is a logical grouping of NSX Edge interfaces that belong to the same failure domain. A failure domain is a set of NSX Edge nodes that share the same physical network infrastructure and are subject to the same network failures. By configuring an Interface Group, you can ensure that the stateful services are distributed across different failure domains and can recover from network failures1

To verify that VMware Identity Manager integration is successful with NSX, the administrator should check the NSX UI for the integration status. If it is configured correctly, the status should be marked as "Enabled," indicating that the integration is active and functioning.

According to the VMware NSX Documentation1, a segment is mapped to a unique Geneve segment that is distributed across the ESXi hosts in a transport zone. The Geneve segment uses a virtual network identifier (VNI) as an overlay network identifier. The VNI ID can be used to identify overlay segments in an NSX environment if troubleshooting is required.
