Free Access Nokia.4A0-C02.v2022-06-01.q164 Practice Test (Page 16)

Question 71

A customer has two sites connected to PE-1 and a third site dual-homed to PE-2 and PE-3. If BGP is used as the PE-CE protocol, what is the total number of BGP and MP-BGP sessions required on PE-1 for a functional VPRN service? Assume that route reflection is not used.

A.1 BGP and 2 MP-BGP sessions

B.0 BGP and 2 MP-BGP sessions

C.2 BGP and 0 MP-BGP sessions

D.2 BGP and 2 MP-BGP sessions

E.2 BGP and 1 MP-BGP sessions

Question 72

Which of the following statements regarding BGP Add-Paths is FALSE?

A.Add-Paths allows non-best paths to be advertised to a peer.

B.A BGP speaker must advertise the capability to receive multiple paths from its peer.

C.A BGP speaker must advertise the capability to send multiple paths to its peer.

D.Add-Paths capabilities are exchanged between peers after the BGP session is established.

Question 73

Which of the following about VPRN Outbound Route Filtering (ORF) is FALSE?

A.BGP ORF allows a receiving PE to filter out unnecessary inbound routes.

B.Resources consumed at the sender and receiver PEs can be reduced by using BGP ORF.

C.BGP ORF is most effective when a large number of routes is being exchanged between two peers, and most routes are filtered out on arrival.

D.A PE indicates its ORF capabilities to its neighbor PE in a BGP Open message.

Question 74

Click the exhibit.

For the Carrier Supporting Carrier (CSC) VPRN, which routes are advertised between CSC-CE1 andCSC-PE1?

A.BGP labeled IPv4 routes for all PE system addresses in AS 1000

B.BGP labeled IPv4 routes for all PE system addresses in AS 5000

C.VPN-IPv4 routes for all PE system addresses in AS 1000

D.VPN-IPv4 routes for all PE system addresses in AS 5000

Question 75

Click the exhibit.

Community lists are configured for the PE hub and spoke VPRN. Which communities should be exported by the VPRN service on PE1?

A."Hub_Site"

B.No communities should be exported

C."Spoke.Sites" and "Hub_Site"

D."Spoke_Sites"
