Question 31

Regarding the multicast distribution tree model SPT, the correct statement below is ______.

A.Each router on the SPT will maintain (S, G) entries

B.Different multicast sources take themselves as the root and establish SPT independently

C.Each router on the SPT will maintain (*, G) entries

D.In the SPT model, the path taken by the multicast source to reach any receiver is optimal

Question 32

What kind of request operation does SNMP v2c add to the SNMP v1 protocol?

A.GetRequest

B.GetNextRequest

C.SetRequest

D.GetBulkRequest

Question 33

The figure shows the application of SmartLink and RRPP hybrid networking. In this networking environment, the RRPP protocol is enabled on the switch SWA, switch SWB, switch SWC and switch SWD to provide link redundancy backup. From the above information, you can know

A.Switch SWC, switch SWD, switch SWE use SmartLink technology, switch SWE uplink switch SWC, switch SWD link will block one

B.Switch SWC, switch SWD, switch SWE can use MSTP technology to avoid loops

C.Switch SWC, switch SWD, switch SWE use MSTP technology, switch SWE uplink switch SWC, switch SWD link will block one

D.Switch SWC, switch SWD, switch SWE can use SmartLink technology to avoid loop

Question 34

Which of the following aspects should be considered for the security of the campus network?

A.Effective access control

B.Protect the physical circuit

C.Effective management of network equipment and network topology

D.Effectively identify legal and illegal users

Question 35

In the PIM-DM network as shown in the figure, part of the unicast routing tables of routers RT1 and RT2 are as follows:
<RT1>display ip routing-table
Routing Tables: Public
Destination/MaskProtoPreCost NextHop Interface
1.1.1.0/24xxxxP1-1 C1-110.1.1.1Port1
1.1.0.0/16xxxxP1-2 C1-210.1.1.1Port1
<RT2>display ip routing-table
Routing Tables: Public
Destination/MaskProtoPreCost NextHop Interface
1.1.1.0/24XXXX P2-1 C2-111.1.1.1Port2
1.1.1.1/32XXXX P2-2 C2-211.1.1.1Port2
Then, when routers RT1 and RT2 perform Assert, the winner should be

A.If P1-1> P2-1, C1-1<C2-1, then RT1 wins

B.If P1-1=P2-1, C1-1<C2-1, RT1 wins

C.If P1-1=P2-2, C1-1<C2-2, RT2 wins

D.If P1-1> P2-2, C1-1<C2-2, then RT2 wins

E.If P1-1=P2-2, C1-1=C2-2, then RT2 wins

F.If P1-1=P2-1, C1-1=C2-1, then RT1 wins
