Fragmented IP packets are often used to evade firewalls or intrusion detection systems.
Port Scanning is one of the most popular reconnaissance techniques attackers use to discover services they can break into. All machines connected to a Local Area Network (LAN) or Internet run many services that listen at well-known and not so well known ports.
A port scan helps the attacker find which ports are available (i.e., what service might be listing to a port).
One problem, from the perspective of the attacker attempting to scan a port, is that services listening on these ports log scans. They see an incoming connection, but no data, so an error is logged. There exist a number of stealth scan techniques to avoid this. One method is a fragmented port scan.
Fragmented packet Port Scan
The scanner splits the TCP header into several IP fragments. This bypasses some packet filter firewalls because they cannot see a complete TCP header that can match their filter rules. Some packet filters and firewalls do queue all IP fragments, but many networks cannot afford the performance loss caused by the queuing.

Explanation
If all company users worked in the same office with one corporate network and using company supplied laptops, then it is easy to implement all sorts of physical security controls. Examples of physical security include intrusion detection systems, fire protection systems, surveillance cameras or simply a lock on the office door.
However, in this question we have dispersed employees using their own devices and frequently traveling internationally. This makes it extremely difficult to implement any kind of physical security.
Physical security is the protection of personnel, hardware, programs, networks, and data from physical circumstances and events that could cause serious losses or damage to an enterprise, agency, or institution.
This includes protection from fire, natural disasters, burglary, theft, vandalism, and terrorism.

Check the solution below.
Screen Shot 2015-04-09 at 10
Task 1) An administrator added a rule to allow their machine terminal server access to the server subnet. This rule is not working. Identify the rule and correct this issue.
The rule shown in the image below is the rule in question. It is not working because the action is set to Deny.
This needs to be set to Permit.
Task 2) All web servers have been changed to communicate solely over SSL. Modify the appropriate rule to allow communications.
The web servers rule is shown in the image below. Port 80 (HTTP) needs to be changed to port 443 for HTTPS (HTTP over SSL).
Task 3) An administrator added a rule to block access to the SQL server from anywhere on the network. This rule is not working. Identify and correct this issue.
The SQL Server rule is shown in the image below. It is not working because the protocol is wrong. It should be TCP, not UDP.
Task 4) Other than allowing all hosts to do network time and SSL, modify a rule to ensure that no other traffic is allowed.
The network time rule is shown in the image below.
However, this rule is not being used because the 'any' rule shown below allows all traffic and the rule is placed above the network time rule. To block all other traffic, the 'any' rule needs to be set to Deny, not Permit and the rule needs to be placed below all the other rules (it needs to be placed at the bottom of the list to the rule is enumerated last).

In this question, we have an unauthorized mail server using the IP: 192.168.2.55.
Blocking port 25 on the firewall for all unauthorized mail servers is a common and recommended security step. Port 25 should be open on the firewall to the IP addresses of the authorized email servers only (192.168.2.10 and 192.168.2.11). This will prevent unauthorized email servers sending email or receiving and relaying email.
Email servers use SMTP (Simple Mail Transfer Protocol) to send email to other email servers. Shutting down the SMTP service on the unauthorized mail server is effectively disabling the mail server functionality of the unauthorized server.
Incorrect Answers:
A: You shouldn't worry about identifying the origination point for the malicious activity on the unauthorized mail server. There isn't much you could do about the remote origination point even if you did identify it. You have an 'unauthorized' mail server. That is what you should be dealing with.
C: In this question, the email was received by the unauthorized email server (192.168.2.55) ready to be collected by the recipient. The email was not relayed (forwarded) to other email servers. Disabling open relay functionality will not stop the emails. You need to disable all email (SMTP) functionality of the unauthorized server, not just relaying.
E: STARTTLS enables TLS encryption on communications with the spam filter. It will do nothing to prevent the usage of the unauthorized email server.
References:
https://en.wikipedia.org/wiki/Simple_Mail_Transfer_Protocol
https://www.arclab.com/en/kb/email/how-to-read-and-analyze-the-email-header-fields-spf-dkim.html
